12V9 Resin Bond Diamond Grinding Wheel for Sharpening Carbide Knives

12V9 Resin Bond Diamond Grinding Wheel for Sharpening Carbide Knives

  • 12V9 Resin Bond Diamond Grinding Wheel for Sharpening Carbide Knives
  • 12V9 Resin Bond Diamond Grinding Wheel for Sharpening Carbide Knives
  • 12V9 Resin Bond Diamond Grinding Wheel for Sharpening Carbide Knives
  • 12V9 Resin Bond Diamond Grinding Wheel for Sharpening Carbide Knives
12V9 Resin Bond Diamond Grinding Wheel for Sharpening Carbide Knives
Détails sur le produit:
Lieu d'origine: Chine
Nom de marque: Shine Abrasives
Certification: ISO
Numéro de modèle: 4V2 1A1 14A2 9A3 12V9
Conditions de paiement et expédition:
Quantité de commande min: 2 pièces
Prix: FOB
Détails d'emballage: une en carton
Délai de livraison: 5 jours ouvrables
Conditions de paiement: LC, T/T
Capacité d'approvisionnement: 1000 PCS en une semaine
Contact
Description de produit détaillée
tasse: 5/8 pouces, 1 pouce Profondeur de l'abrasif: 1/4 pouce
Nombre de trou de roue: Varie largeur de roue: 10mm
Résistance à la roue: Résine Vitesse: Haut
Couleur de la roue: Varie Qualité: Haut
Collage: vitrifié, métal Viscosité: Bien
Taille des grains: Personnalisé méthode de refroidissement: Séché, mouillé
Style: 1V1 Structure: Densité
Résistance à l'abrasion: Haut
Mettre en évidence:

12V9 resin bond diamond wheel

,

diamond grinding wheel for carbide knives

,

sharpening wheel for carbide tools

12V9 Resin Bond Diamond Grinding Wheel for Sharpening Carbide Knives

12V9 resin diamond grinding wheel is mainly used for cylindrical grinding and cutting edge processing of cemented carbide.It is suitable for grinding metal and non-metal hard and brittle materials with low iron content,such as cemented carbide,high alumina porcelain, optical glass, agate gemstone, semiconductor material, ceramics, stone, etc.



D T H X V
mm Inch mm Inch state bore dimension mm Inch 70°
75 3 35 1-1/4 3-6 1/8-1/4
100 4 35 1-1/4 3-6 1/8-1/4
125 5 35 1-1/4 3-6 1/8-1/4
150 6 35 1-1/4 3-6 1/8-1/4
Other dimensons are available on request



Resin diamond grinding wheel for sharpening carbide tools are used for tungsten carbide, high speed steel (HSS), stainless drill,end mill and reamer. We will provide a complete solution for tools manufacturing process, including fluting, gashing and clear edge, relief angle grinding .

12V9 Resin Bond Diamond Grinding Wheel for Sharpening Carbide Knives 0
