Name: Hybrid bond CNC diamond wheel for high-performance flute grinding
Brand: ZHENGZHOU SHINE ABRASIVES CO.,LTD
SKU: 4V2 1A1 14A2 1V1
Price: 50.00 USD
Availability: InStock

Aperçu Produits Roues de meulage CNC

Hybrid bond CNC diamond wheel for high-performance flute grinding

Détails sur le produit:

Lieu d'origine:	CHINE
Nom de marque:	Shine Abrasives
Certification:	ISO
Numéro de modèle:	4V2 1A1 14A2 1V1

Conditions de paiement et expédition:

Quantité de commande min:	2 PCS
Prix:	FOB
Détails d'emballage:	une en carton
Délai de livraison:	5 jours de travail
Conditions de paiement:	L / C, T / T
Capacité d'approvisionnement:	1000 PCS en une semaine

Contact

Description de produit détaillée

Application:	Machines CNC	Vitesse:	6000 tr / min
Couleur:	Argent	Pression maximale:	5MPA
Taille:	6 pouces	tasse:	7/8 pouce
Température maximale:	150°C	Taille de bordure de diamant:	6x6mm
Type d'obligation:	Des hybrides	Lier:	Résine
Code HS:	6804211000	Efficacité:	RAPIDE
Vitesse maximale:	100m / s	Rpm maximale:	6000 tr / min
Dureté:	Haut
Mettre en évidence:	Hybrid bond CNC diamond wheel , CNC flute grinding wheel , high-performance diamond grinding wheel

Hybrid bond CNC diamond wheel for high-performance flute grinding

Hybrid bond CNC diamond wheel for high-performance flute grinding.Hybrid bond is Resin Bond, Metal Bond, and or processing methods to create a Hybrid that encompasses enhanced properties to deliver high performance results for some of manufacturing’s toughest grinding applications.

Wheel sizes form:

Diameter of D	Diamond depth of U	R	X	H
50mm	2,3,4,5,6,7,8,9,10	1/2 U	3 or 5 or 6	12.7,20,25.4 32 customize
75mm	2,3,4,5,6,7,8,9,10	1/2 U	3 or 5 or 6	12.7,20,25.4 32 customize
100mm	2,3,4,5,6,7,8,9,10	1/2 U	3 or 5 or 6	12.7,20,25.4 32 customize
125mm	2,3,4,5,6,7,8,9,10	1/2 U	3 or 5 or 6	12.7,20,25.4 32 customize
150mm	2,3,4,5,6,7,8,9,10	1/2 U	3 or 5 or 6 or 10	12.7,20,25.4 32 customize
175mm	2,3,4,5,6,7,8,9,10	1/2 U	3 or 5 or 6 or 10	12.7,20,25.4 32 customize
200mm	2,3,4,5,6,7,8,9,10	1/2 U	3 or 5 or 6 or 10	12.7,20,25.4 32 customize

Others sizes are available per requested.

*Grinding, PCD, PCBN, CVD, MCD, hard alloy and other cutting tools

*Bonding agents: ceramic bonding agents, resin bonding agents, metal bonding agents

*The particle size can reach up to 10000#

*Cutting edge quality less than 5 microns

*Provide dressing wheels to trim PCD grinding wheels
*Precision grinding: capable of achieving high accuracy and surface finish
*The bowl is mainly used for tool sharpening and surface milling, suitable for grinding metal and non-metal hard and brittle material with low iron content.
